Suntek is a professional PCBA solution provider,specilizes in PCB production,components procurement,PCB assembly and a series service of wire harness and Box building.
We have high-qualified management team, experienced engineering,quality control&production team and skilled employees and possess advantaged supply chain,commitment to good quality,competitive price and on-time on delivery.
Product Description:
| Project |
SMT processing capacity |
| SMT capacity |
10 million solder joints/day |
| Surplus |
Resistance and capacitance: 0.3% |
| IC: 0% |
| Board type |
POP/PCB/FPC/Rigid-flex board/HDI/High Frequency&Speed
PCB/Metal-PCB |
| Mounting component precision |
Minimum package: 03015CHIP/0.20PLT |
| Minimum Component Accuracy:±0.034MM |
| IC placement accuracy: ± 0.025MM |
| PCB SPEC |
PCB size: 50*50MM~774*710MM |
| PCB thickness: 0.3~6.5MM |
Certificates:
With ISO9001:2015,ISO13485:2016,IATF 16949:2016 and UL E476377 certified,
Equipment
We have advanced production equipments and Testing machines.
Applications:
We have advanced manufacturing equipments,professional technology,professional
engineer team,purchasing team,quality team and management team to guarantee
the high quality products and on time delivery.Our products are widely used in
industrial control,auto,telecommunications,medical equipment,consumer electronics and etc.
Key Features:
High-quality FR-4 material for reliable and efficient assembly
Available in white, black, and yellow silkscreen colors for enhanced visual appeal
Compact dimensions of 76*31*4.5mm (L*W*H) for versatile use in various medical devices
Specialized service for medical system PCB integration and healthcare device electronics assembly
Ensures accurate and reliable results for medical offices, testing facilities, and medical device manufacturers
SMT PCB Assembly Process - Surface Mount Technology
In the fast-paced world of electronics manufacturing, surface mount technology (SMT) assembly is a pivotal innovation that has reshaped the way we produce printed circuit boards (PCBs). This article will take you on an in-depth look at the SMT assembly process as well as the pros and cons!
What is SMT assembly?
SMT, its full name is "surface-mount technology". SMT assembly is the method to place and solder the electronic components on the surface of PCB correctly by using automated machine. With the development of smart technology today, SMT assembly has replaced traditional through-holes technology construction method of fitting electronic components, SMT assembly allows to increase manufacturing automation so that it reduce the manufacturing cost of PCBs greatly and lead to smaller board.
Packaging and Shipping
Our Medical PCB Assembly products are carefully packaged and shipped to ensure their safe delivery to our customers. We understand the importance of maintaining the quality and integrity of our products, especially in the medical industry. That's why we follow strict packaging and shipping guidelines to ensure that our products arrive at their destination in perfect condition.
Our supports
We ensure cost transparency, BOM cost breakdown sharing
We have components suppliers from the Global.
We have a written process to advise customers of any schdule delays or product quality problems,by:
(1)Customer service procedure
(2)RMA procedure
(3)8D reports
(4)PDCA(Plan-Do-Check-Action) in customer service
We respond to the complaints,issues and queries in 24 hours, by:
(1) Weekly reports
(2) Customer supporting team to review communication times
(3) Customer satisfaction questionnaire
Aftersales services:
(1) 1-year guarantee period for all of products
(2) FOC repair
(3) Quick compensation parts to replace defectives.
